What this report does
Lists all equipment records added to components via the Component Equipment module during the selected date range. Each row represents a piece of equipment installed on a component — showing the installation date, why it was installed, who installed it, and the equipment details including model, manufacturer, Low-E designation, packing, stem type, gasket type, and MOC reference.
Use this report to audit equipment installations, verify that Low-E models and packing are correctly recorded, and confirm MOC references for equipment changes. This report is available directly on the Reports tab.
When to use it
- Reviewing all equipment installed during a compliance period or audit window.
- Verifying that newly installed Low-E components have the correct model and packing recorded.
- Confirming MOC references on equipment change records.
- Filtering installations to a specific model or packing type.
Parameters
| Parameter | Description | Required | How it filters |
|---|---|---|---|
| Start Date | Beginning of date window | Yes | Equipment installed on or after this date is included; timezone-aware per component location |
| End Date | End of the date window | Yes | Equipment installed on or before this date is included; expanded to end of day |
| Regulations | One or more regulations to filter by | Yes | Only components mapped to the selected regulation(s) appear |
| Unit Type | Whether to filter by Process Unit or Location Unit | Yes | Determines which unit list populates |
| Units | One or more units to include | Yes | Only components in the selected units appear |
| Comp Types | One or more component types to include | Yes | Only the selected component types appear |
| Models | One or more equipment models to filter by; select All Models to show all | Yes | Filters by standard model or Low-E model |
| Low-E Packing | One or more Low-E packing types to filter by; select All Models to show all | Yes | Filters by Low-E packing type |
Columns
| Column | What it shows | Format / Notes |
|---|---|---|
| Unit | The unit the component belongs to | Text |
| Tag | Component tag number | Text |
| Type | Component type (level 1) | Text; e.g., "Valve", "Connector", "Pump" |
| Date Installed | Date the equipment was installed | Date; displayed in the component's local time zone |
| Install Why | The reason the equipment was installed | Text; the installation reason description (e.g., "LowE Requirement", "Replacement") |
| Installed By | Name of the person who installed the equipment | Text; free-text entry as recorded on the equipment record |
| Manufacturer | Equipment manufacturer | Text; manufacturer description from the equipment record |
| Model | Equipment model name or code | Text; shows the Low-E model if one is assigned, otherwise the standard model |
| Low-E | Whether this is a Low-E equipment record | Text; "Yes" if a Low-E model is assigned; "No" otherwise |
| Serial Number | Equipment serial number | Text; blank if not recorded |
| Low-E Packing | Low-E packing type installed | Text; blank if no Low-E packing is recorded |
| MOC Ref | MOC reference number or code | Text; blank if no MOC reference is recorded |
| Stem Type | Valve stem type | Text; blank if not recorded or not applicable |
| Gasket Type | Valve gasket type | Text; blank if not recorded or not applicable |
What's included and excluded
Included:
- Only equipment records with a DateInstalled within the selected date range.
- Only components of the selected type(s) mapped to the selected regulation(s).
- Only components in the selected unit(s).
- When specific models are selected: only records matching the selected standard model or Low-E model.
- When specific Low-E packing is selected: only records matching the selected packing type.
Excluded:
- Components not mapped to the selected regulation(s).
- Equipment records with DateInstalled outside the date range.
- Component types not selected.
How key values are calculated
Date Installed
The date the equipment record was created in the Component Equipment module, converted to the component's local time zone.
Model and Low-E
The Model column shows the Low-E model description if one is assigned; if not, it falls back to the standard equipment model description. The Low-E column shows "Yes" when a Low-E model is assigned and "No" otherwise. A component can have both a standard model and Low-E model — Low-E takes precedence in the Model column.
Most recent record per component
When a component has multiple equipment records installed during the window, only the most recently installed one is returned. Each component produces at most one row.
Tips and common questions
- "I see a component I expected but its Model column is blank." The equipment record was installed without a model selected. Use the Component Equipment section of the tag view to review and update the record.
- "Low-E shows 'No' but I know this is a Low-E valve." The Low-E designation comes from the equipment record — specifically whether a Low-E Model was selected in the Component Equipment module. If the standard model was used instead of the Low-E model, Low-E will show "No" even for valves that are physically Low-E.
- "Stem Type and Gasket Type are blank for most rows." These fields are only populated for valves where stem and gasket information was entered in the Component Equipment module. They are optional fields.
- "Why does selecting 'All Models' and 'All Packing' show all records?" The Models and Low-E Packing parameters are filters that narrow to specific equipment types. Selecting "All Models" / "All Models" for both shows every installed equipment record regardless of model or packing.
- "I have multiple equipment records for the same component but only one row appears." The report shows only the most recent installation within the date window per component. If earlier records are needed, review the Component Equipment history on the tag view.
- "Only one equipment record appears per component even though multiple were installed in the date range." This report shows only the most recently installed equipment record per component within the selected date range. Earlier installations for the same component are not shown. For a full installation history, review the component's equipment tab in Chateau.
- "The InstalledBy column shows a long alphanumeric code instead of a name for some records." Older equipment records may have a system identifier stored in the InstalledBy field rather than a technician name. This is a data quality issue with historical records. Newer records entered through the standard Chateau workflow will display the technician's name.
Sample output
Report run for Example Facility, StartDate: 9/1/2024, EndDate: 9/30/2024, Regulations: Regulation 1, Unit Type: Location Unit, Models: All, Low-E Packing: All, Units: Demo-1, Demo-2, Comp Type: Valve.
What the rows illustrate:
Tag 000200 (Demo 1) — Low-E Packing without a Low-E Model: Low-E = No and Model is blank, yet Low-E Packing = "Low-E Pack 3" and MOC Ref = "124ABC_PACK" are populated. This illustrates that Low-E Packing can be recorded independently of a Low-E Model — the two fields are separate, and a component can have packing data without a qualifying Low-E model assigned. Install Why = "Replacement In Kind."
Tag 000002 (Demo 2) — Full Low-E record with stem and gasket: Low-E = Yes, Model = Model 1, Serial Number = 123ABD, MOC Ref = 123-ABD-REF, Stem Type = Rising, Gasket Type = Gasket 1. This is the most complete record in the sample, with all optional valve-specific fields populated. Install Why = "Added To Existing Unit."
Tag 000001 (Demo 2) — Low-E Packing without a Low-E Model (second example): Like tag 000200, Low-E = No and Model is blank, but Low-E Packing = "Low-E Pack 1" is recorded. Stem Type and Gasket Type are blank. Install Why = "New Component."
Tag 000008 (Demo 2) — Low-E Model and Packing both populated: Low-E = Yes, Model = Model 2, Low-E Packing = "Low-E Pack 1", MOC Ref = 123ABF-REF. Stem Type and Gasket Type are blank, showing that a complete Low-E designation does not require stem and gasket data. Install Why = "New Component."
Output format
One row per component (most recently installed equipment within the window). Suitable for on-screen viewing, PDF, and Excel export.
Related reports
- Activated Components with Equipment — shows newly activated components together with their equipment data; focuses on component activation date rather than equipment installation date.
- CVS-NDE Inspection History — includes Model and Packing data alongside inspection history for CVS and NDE components.
